ENGLISHKS-Z203-Double Heads Milling Machine
The machine is developed and designed by adopting mature Italian design idea in combination with the latest application requirement and habit, and the machine is mainly used for processing of the through-ole or blind hole for aluminum curtain wall profiles, and it can also be used for processing aluminum industrial profiles and window profiles.
1. It adopts motor to cylinder output directly; the drilling process has good stability and accuracy.
2. Spindle could be collocated with normal driller and poly-driller, the drilling is with convenience and efficiency.
TECHNICAL PARAMETER
|
Model and parameters |
KS-Z203
Double Heads Milling Machine |
|
Standard configuration head |
2pcs or more |
|
Dimension of worktable (L *W) |
250x230mm |
|
Maximum moving distance of spindle from front to back |
60mm |
|
maximum moving distance of spindle from up to down |
150mm |
|
Rotating speed of Motor |
1400r/min |
|
Motor power |
1.5Kw X 2 |
|
Maximum diameter of drilling hole |
φ15mm |
|
Minimum diameter of drilling hole |
φ3mm |
|
Minimum hole distance for each group |
235mm |
|
Minimum hole distance for single group (porous device) |
13.5-22mm |
|
Working air pressure |
0.6-0.8Mpa |
|
Working voltage |
380VAC/50HZ |
|
Overall Dimension (L*W*H) |
2300×1400×1200 mm |
|
Weight of machine |
800kg |
|
Optional device, function |
Digital display function |
|
Retrofit movable pneumatic drill seat | |
|
Clamps, positioning template | |
|
Spare tool |
